  • WCN1-3015A-AUL3-PTFE-100C

    • WCN1-3015A-AUL3-PTFE-100C

    $116.48
    (No reviews yet) Write a Review
    SKU:
    WCN1-3015A-AUL3-PTFE-100C
    For PDF Spec:
    For STEP File:
    Type:
    Weld Field Immune Proximity Sensors
    Shape:
    Cylindrical
    Diameter:
    M30
    Sensing Range:
    15 mm Range
    Mounting Style:
    Shielded
    Output Type:
    AC
    Output Function:
    Normally Open
    Connection:
    3 Pin Quick Disconnect
    Connector:
    1/2-20UNF Connector
    Body Length:
    81 mm
    Housing Material:
    SpatterGuard coated Brass
    Sensing Face Material:
    PBT Plastic
    IP Rating:
    IP67
    Operating Temperature:
    -20 C - +100 C
    Operating Voltage:
    20-250 V AC
    Current Consumption:
    <1.8 mA
    Leakage Current:
    <1.8 mA
    Max Current:
    400 mA
    Overload Trip Point:
    -
    Surge Current:
    5 A (20 ms)
    Short Circuit Protected:
    NO
    Reverse Polarity Protected:
    NO
    Switching Frequency:
    <25 Hz
    Response Time:
    10 ms/10 ms
    EMC Rating:
    RFI>3V/m / EFT>1kV / ESD>4Kv (contact)
    Shock/Vibration Rating:
    IEC 60497-5-2 Part 7.4.1&7.4.2
    Weld Field Immune:
    Yes
    Weld Spatter Resistant:
    Yes - SpatterGuardª Coated
    Description:
    M30, 15 mm Range, AC, Normally Open
    Matching Cable:
    U-FS3TAV315 (Straight Connector) / U-FA3TAV315 (Angled Connector)
    Matching Bracket:
    HRAB-30 (Basic) / QT-30 (Quick Release)
    Adding to cart… category.add_cart_announcement

    Product Description

    M30, Weld Field Immune Proximity Sensors, Shielded, 15 mm Range, AC, Normally Open, 1/2-20UNF Connector

    Product Videos

    Custom Field

    For PDF Spec
    For STEP File
    Type Weld Field Immune Proximity Sensors
    Shape Cylindrical
    Diameter M30
    Sensing Range 15 mm Range
    Mounting Style Shielded
    Output Type AC
    Output Function Normally Open
    Connection 3 Pin Quick Disconnect
    Connector 1/2-20UNF Connector
    Body Length 81 mm
    Housing Material SpatterGuard coated Brass
    Sensing Face Material PBT Plastic
    IP Rating IP67
    Operating Temperature -20 C - +100 C
    Operating Voltage 20-250 V AC
    Current Consumption <1.8 mA
    Leakage Current <1.8 mA
    Max Current 400 mA
    Overload Trip Point -
    Surge Current 5 A (20 ms)
    Short Circuit Protected NO
    Reverse Polarity Protected NO
    Switching Frequency <25 Hz
    Response Time 10 ms/10 ms
    EMC Rating RFI>3V/m / EFT>1kV / ESD>4Kv (contact)
    Shock/Vibration Rating IEC 60497-5-2 Part 7.4.1&7.4.2
    Weld Field Immune Yes
    Weld Spatter Resistant Yes - SpatterGuardª Coated
    Description M30, 15 mm Range, AC, Normally Open
    Matching Cable U-FS3TAV315 (Straight Connector) / U-FA3TAV315 (Angled Connector)
    Matching Bracket HRAB-30 (Basic) / QT-30 (Quick Release)
