  • FQP2-4030A-AUL3

    • FQP2-4030A-AUL3

    $157.04
    (No reviews yet) Write a Review
    SKU:
    FQP2-4030A-AUL3
    For PDF Spec:
    For STEP File:
    Type:
    Inductive
    Shape:
    Square
    Dimensions:
    130 mmx40 mmx40 mm
    Sensing Range:
    30 mm Range
    Mounting Style:
    Unshielded
    Output Type:
    AC
    Output Function:
    Normally Open
    Connection:
    3 Pin Quick Disconnect
    Connector:
    1/2-20UNF Connector
    Housing Material:
    PBT
    Sensing Face Material:
    PBT Plastic
    IP Rating:
    IP67
    Operating Temperature:
    -25 C - +70 C
    Operating Voltage:
    24-240 V AC
    Current Consumption:
    <1.8 mA
    Leakage Current:
    <1.8 mA
    Max Current:
    400 mA
    Overload Trip Point:
    -
    Surge Current:
    5A for 20ms
    Short Circuit Protected:
    #N/A
    Reverse Polarity Protected:
    #N/A
    Switching Frequency:
    25Hz
    Response Time:
    10ms
    EMC Rating:
    RFI>3V/m / EFT>1kV / ESD>4Kv (contact)
    Shock/Vibration Rating:
    IEC 60497-5-2 Part 7.4.1&7.4.900
    Weld Field Immune:
    #N/A
    Weld Spatter Resistant:
    #N/A
    Description:
    Rectangular, 30mm, AC, Normally Open
    Matching Cable:
    U-FS3TAV315 (Straight Connector) / U-FA3TAV315 (Angled Connector)
    Adding to cart… category.add_cart_announcement

    Product Description

    Rectangular, #N/A, Unshielded, 30mm, AC 2-Wire, Normally Open, 1/2-20UNF Connector

    Product Videos

    Custom Field

    For PDF Spec
    For STEP File
    Type Inductive
    Shape Square
    Dimensions 130 mmx40 mmx40 mm
    Sensing Range 30 mm Range
    Mounting Style Unshielded
    Output Type AC
    Output Function Normally Open
    Connection 3 Pin Quick Disconnect
    Connector 1/2-20UNF Connector
    Housing Material PBT
    Sensing Face Material PBT Plastic
    IP Rating IP67
    Operating Temperature -25 C - +70 C
    Operating Voltage 24-240 V AC
    Current Consumption <1.8 mA
    Leakage Current <1.8 mA
    Max Current 400 mA
    Overload Trip Point -
    Surge Current 5A for 20ms
    Short Circuit Protected #N/A
    Reverse Polarity Protected #N/A
    Switching Frequency 25Hz
    Response Time 10ms
    EMC Rating RFI>3V/m / EFT>1kV / ESD>4Kv (contact)
    Shock/Vibration Rating IEC 60497-5-2 Part 7.4.1&7.4.900
    Weld Field Immune #N/A
    Weld Spatter Resistant #N/A
    Description Rectangular, 30mm, AC, Normally Open
    Matching Cable U-FS3TAV315 (Straight Connector) / U-FA3TAV315 (Angled Connector)
