  • FCS1-3010N-BRU4

    • FCS1-3010N-BRU4

    $139.36
    (No reviews yet) Write a Review
    SKU:
    FCS1-3010N-BRU4
    For PDF Spec:
    For STEP File:
    Type:
    Inductive Metal Face Proximity Sensor
    Shape:
    Cylindrical
    Diameter:
    M30
    Sensing Range:
    10 mm Range
    Mounting Style:
    Shielded
    Output Type:
    NPN
    Output Function:
    Normally Closed
    Connection:
    4 Pin Quick Disconnect
    Connector:
    M12 A Coded Connector
    Body Length:
    78 mm
    Housing Material:
    Stainless Steel SUS303
    Sensing Face Material:
    1-Piece Stainless Steel
    IP Rating:
    IP68
    Operating Temperature:
    -25 C - +70 C
    Operating Voltage:
    10-30 V DC
    Current Consumption:
    <10 mA
    Leakage Current:
    <0.01 mA
    Max Current:
    200 mA
    Overload Trip Point:
    >220 mA
    Surge Current:
    -
    Short Circuit Protected:
    Yes
    Reverse Polarity Protected:
    Yes
    Switching Frequency:
    300 Hz
    Response Time:
    0.5 ms/0.5 ms
    EMC Rating:
    RFI>3V/m / EFT>1kV / ESD>4Kv (contact)
    Shock/Vibration Rating:
    IEC 60497-5-2 Part 7.4.1&7.4.2
    Weld Field Immune:
    No
    Weld Spatter Resistant:
    No
    Description:
    M30, 10 mm Range, NPN, Normally Closed
    Matching Cable:
    R-FS4TZ-V075 (Straight Connector) / R-FA4TZ-V075 (Angled Connector)
    Matching Bracket:
    HRAB-30 (Basic) / QT-30 (Quick Release)
    Adding to cart… category.add_cart_announcement

    Product Description

    M30, Inductive Metal Face Proximity Sensor, Shielded, 10 mm Range, NPN, Normally Closed, M12 A Coded Connector

    Product Videos

    Custom Field

    For PDF Spec
    For STEP File
    Type Inductive Metal Face Proximity Sensor
    Shape Cylindrical
    Diameter M30
    Sensing Range 10 mm Range
    Mounting Style Shielded
    Output Type NPN
    Output Function Normally Closed
    Connection 4 Pin Quick Disconnect
    Connector M12 A Coded Connector
    Body Length 78 mm
    Housing Material Stainless Steel SUS303
    Sensing Face Material 1-Piece Stainless Steel
    IP Rating IP68
    Operating Temperature -25 C - +70 C
    Operating Voltage 10-30 V DC
    Current Consumption <10 mA
    Leakage Current <0.01 mA
    Max Current 200 mA
    Overload Trip Point >220 mA
    Surge Current -
    Short Circuit Protected Yes
    Reverse Polarity Protected Yes
    Switching Frequency 300 Hz
    Response Time 0.5 ms/0.5 ms
    EMC Rating RFI>3V/m / EFT>1kV / ESD>4Kv (contact)
    Shock/Vibration Rating IEC 60497-5-2 Part 7.4.1&7.4.2
    Weld Field Immune No
    Weld Spatter Resistant No
    Description M30, 10 mm Range, NPN, Normally Closed
    Matching Cable R-FS4TZ-V075 (Straight Connector) / R-FA4TZ-V075 (Angled Connector)
    Matching Bracket HRAB-30 (Basic) / QT-30 (Quick Release)
